Other Bulleid 4mm Scale Coaches:
Bachmann
The ready to run Bulleids from Bachmann represent the slightly later variety
with the deeper 15" sliding vents introduced under BR. The sets that can
be made up from the Bachmanns are numbers 80 - 94 (4-coach sets), 767 - 769
(3-coach Sets) and 830 - 849 (4-coach Sets), although they are also very close
to sets 850 - 865.
I have modelled 4-coach set s83 as introduced in 1949 (BSK, SK, CK, BSK) in
Southern Malachite Green but without the Southern ownership lettering on the
sides. This required the original Bachmann decals to be removed using cotton
buds soaked in white spirit (I would point out that this was simple on two out
of the four with the decals just floating away but required quite hard rubbing
on the other two so I am not sure if Bachmann have changed their printing
process at some stage). HMRS Pressfix decals were then used for the tedious
task of renumbering the coaches. I also fitted these with Kadee®Nº5
couplings screwed to the underside of the floor behind the buffer beam.
Southern Pride
Unfortunately the range of Bulleid near flush sided kits from Southern Pride
were withdrawn in 2003 to be updated and improved but there is no news yet on
when they will be re-introduced.
I have made two 3 coach sets (sets 981 & 984) of the early Bulleid 1946
built 64ft 3in coach sets (981 to 984), multi door coaches. These kits were
easy to assemble, simply using Mek Pak or similar plastic solvent. The sides in
these kits were complete with overlays already fixed to the glazing (I am yet
to try one of the Southern Pride kits needing the overlays to be fixed by
builder) My only gripe is that I find the Malachite pre coloured sides to be a
shade to light for my liking and if anything I find the sides too flush. The
early Southern Pride kits came with white metal bogies that I replaced with the
Phoenix "Adjustaride", whilst towards the end of their production the
kits were supplied complete with Bachmann bogies
Ian Kirk, now Colin Ashby
Following on from the kits for Maunsell stock it was a natural progression to
produced kits for the original Bulleid 1945/6 built 59ft 3-Coach sets (963 to
980), multi door coaches built on Maunsell under frames. The sides supplied
with these kits have the incorrect tumblehome (more like a Maunsell side than a
Bulleid). This can be fairly simply corrected by dunking the sides in very hot
water and with the top and bottom of the sides supported off the workbench
weighting down the middle longitudinally with a piece of metal bar. The coach
ends and roofs are also of the Maunsell style. I remodelled the coach ends and
replaced the roofs with aluminium section from, I think, MTK. |
